Difficulty
Easy
Steps
11
Time Required
00:25:00
- Change fuel filter on Peugeot 3008 11 steps
Ce tutoriel a été créé par la communauté
User contributed
Introduction
This tutorial is made on Peugeot 3008 2.0 HDi 150
Parts
-
-
Open the hood
-
Remove the engine cover by pulling it upwards
-
The diesel filter is located here
-
-
-
Disconnect the fuel hoses and the sensor by unclipping them
-
To unclip the sensors, you must lift the small white notch then push the white outline of this notch and pull the hose at the same time. If you do not do both manipulations at the same time, the hose will not come out.
-
-
-
Screw in the 4 T30 screws
-
Reconnect the fuel hoses and the sensor by clipping them
-
-
-
Reprime the fuel system by pumping the primer bulb until it becomes hard
-
Replace the engine cover by clipping it in place
-
Cancel: I did not complete this guide.
15 other people completed this guide.
7 Comments
change fuel filter by following this tutorial. very simple to do by following step by step
Tutoriel simple et efficace comme on les aime. Merci.
I changed the fuel filter without disconnecting the hood by simply lifting it after removing the torx screws, this prevents the pump from losing its prime.
Vacuuming the bottom I also think that it is cleaner. For the purge, I think you have to see a professional because I don't know how to do it. If anyone has the tip I'm a taker!
How do you proceed to purge water and air?
